รหัสสินค้า : FMS Ranger 1220mm
Notes to Buyers:
① RTF (Ready to Fly) airplanes come with everything you need to fly in the box. A transmitter, receiver, battery, charger, and all other required electronics are included and pre-installed from the factory.
② PNP (Plug-and-Play) airplanes include the ESC, motor, and servos all pre-installed from the factory. Transmitter, receiver, battery, and charger are not included.
③ Due to a printing error, the packaging may indicate '1220mm Ranger V3 With Reflex V2.' The correct model is '1220mm Ranger V2 With Reflex V3.'
④ A T6 Torx screwdriver is needed to install the vertical stabilizer's connecting rod.
(Customers who have purchased Ranger V2 can log in to their account and redeem a FREE T6 Torx screwdriver with 100 points!)
⑤ For the float-equipped Ranger V2, the plane and floats will be sent as two separate packages.
Specification
|
Wingspan |
1220mm/48in |
|
Overall Length |
947mm/37.3 in |
|
Flying Weight |
1200g/oz (Float Included) |
|
Motor Size |
3136-1200KV |
|
ESC |
20A |
|
Servo |
9g Servo x 5pcs (Float Included) |
|
Radio |
6 Channel (RTF Version) |
|
CG (center of gravity) |
50-60mm (From Leading Edge) |
|
Prop Size |
10*5 2-blade |
|
Recommended Battery |
3S 1300MAH 25C |
|
Battery Compartment |
100*60*40mm |
|
Battery Connector |
XT60 |
|
Aileron |
YES |
|
Elevator |
YES |
|
Rudder |
YES |
|
Flaps |
NO |
|
Retracts |
NO |
|
Approx. Flying Duration |
10 min |
|
Minimum Age Recommendation |
14+ |
|
Experience Level |
Beginner |
|
Assembly Time |
3-10 minutes |
|
Wing Load |
39.4g/dm² (0.11oz/in²) |
|
Wing Area |
25.4dm²(393.7in²) |
